10/100M Fast Ethernet Media Converter (with External Power Supply) SFP Slot

Name: 10/100M Fast Ethernet Media Converter (with External Power Supply) SFP Slot
Brand: E-link China Technology Co.,LTD
SKU: LNK-1100WSFP
Price: 64.00 USD
Availability: InStock

Ürün Ayrıntıları

Menşe yeri: Çin

Marka adı: E-link

Sertifika: ISO9001, CE, ROHS, FCC

Model numarası: LNK-1100WSFP

Ödeme ve Nakliye Şartları

Min sipariş miktarı: 1 adet

Fiyat: negotiate

Ambalaj bilgileri: Medya Dönüştürücü Standart Karton Ambalaj

Teslim süresi: 1-3 İş Günü

Ödeme koşulları: T/T, Western Union, MoneyGram, PayPal

Yetenek temini: 1000/ay

En İyi Fiyatı Bulun

Şimdi iletişime geçin

Özellikler

Açıklama

Özellikler

Vurgulamak:
                                                                                                                                                                                                                                                                                                                                                                                                      External Power Supply Media Converter, 10/100M Media Converter, SFP Slot Media Converter


Giriş türü:	10/100Mbps Fast Ethernet	Dalga boyu:	850nm/1310nm/1550nm
Değiştirme ortalaması:	Medya dönüşümü	Güç tüketimi:	5w
Sıcaklığın korunması:	-40~70ºC	MTBF:	100.000 saat

Giriş türü:	10/100Mbps Fast Ethernet
Dalga boyu:	850nm/1310nm/1550nm
Değiştirme ortalaması:	Medya dönüşümü
Güç tüketimi:	5w
Sıcaklığın korunması:	-40~70ºC
MTBF:	100.000 saat

Açıklama

10/100M Fast Ethernet Media Converter (with External Power Supply) SFP Slot

Model : LNK-1100WSFP

Overview

LNK-1100WSFP is an Ethernet media converter that converts media transmission between

UTP Copper cabling and fiber SFP (Small Form-Factor Plug gable) Transceivers. It complies

with IEEE802.3, IEEE802.3u and IEEE802.3x standards. Presently it supports two types of

media network connections: 10Base-T/100Base-TX, and 1000Base-FX, inter-converting

electrical signals of 10Base-T/100Base-TX twisted pairs with optical signals of 100Base-FX.

It extends the transmission distance of network from 100m via copper cable to 120 km via

fiber optical cables.

Features

► Supporting inter-conversion between adaptive 10Base-T/100Base-TX with 100Base-FX

► Use Port 10/100Base-TX (RJ45), 100Base-FX (SFP slot)

► Supporting full-duplex and half-duplex and its auto-sensed

► Supporting auto-sense of MDI/MDI-X, facilitating system commissioning and installation

► Supporting the transmission of extra-long VLAN packets

► Supporting Quality of Service (QoS) and ensuring the transmission of VoIP packets;

Technical Indexes

Parameter	Specifications
Access mode	10/100Mbps Fast Ethernet
Standard	IEEE802.3 10Base-T Ethernet, IEEE802.3u,100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control
Wavelength	850nm/1310nm/1550nm
Transmission distance	multi-mode Dual-fiber: 2KM
	single mode Dual-fiber: 20/40/60/80 Km
	single mode Single fiber: 20/40/60/80 Km
	Category-5 twisted pairs: 100m
Port	One RJ45 port: for connecting with STP/UTP category-5 twisted pairs
Port	One optical port: SFP 3.3V
Conversion means	Media conversion
BER	<10-9
MTBF	100,000 hours
LED indicator	POWR (power supply); FX LINK/ACT (optical link action); FDX (FX full duplex), TX LINK/ACT (TP cable link/action); TX 100 (TP cable rate 100M), FX100(fiber cable rate 100M)
Power supply	External Power: AC90~264V/DC100~380V input, 5V1A output
Power consumption	5W
Operating temperature	-10~55ºC
Operating humidity	5%~90%
Maintaining temperature	-40~70ºC
Maintaining humidity	5% ~ 90% non-condensing
